DB DRIVE | SKU:
FORMULA-NEO1.5KV2
DB DRIVE AMP NEOv2 MONO - 1 X 750W RMS @ 1 OHM / 1 X 350W RMS @ 2 OH - NEO1.5Kv2
$439.00
Unit price
/
Unavailable
Tax included
Shipping calculated at checkout.
Couldn't load pickup availability
NZ AUTOMOTIVE DISTRIBUTORS LTD - NZAD
_____________________________________
NZ's Favourite online Outlet for Automotive parts including Clutches, Flywheels, Brakes, Water Pumps, Bearings, 4WD Accessories, parts and more.
Description
The NEO Amplifiers include a built-in variable crossovers. The crossover features a variable frequency selection for precise low pass filtering for the NEO1.5Kv2. The NEO4v2 and NEO5v2 also feature the same frequency selection with the option or high pass or low pass filtering. For added low frequency performance the amplifiers are equipped with a selectable 6dB-12dB Bass Boost @ 45Hz.
1 Channel Full Range Class D Technology
2Ω Mono load Capability
Amphibious grade conformal coating on PCB
Audiophile Grade RCA connectors
Variable 12dB High/Low-Pass Crossover Filters
Double Sided Circuit tablet
Compatible with any 4/2Ω Subwoofer
Specifications
GENERAL SPECIFICATIONS
Rated Power @ 14.4 Volts
Dynamic Power Handling
1 x 350 Watts @ 2Ω1 x 750 Watts @ 1Ω
PARAMETERS
THD (100Hz @ 1Ω) 0.04%
Bandwidth (-3 dB) 18Hz ~ 22KHz
Damping Factor (1KHz @ 4Ω) 126
S/N ratio (as weighted @ 1 Volt) 99db
Input Sensitivity 0.20V ~ 9.0V RMS
Minimum Load Impedance 1Ω
Input Pre in RCA
Mono Low Pass filter slope 12dB
Low Pass filter range 30Hz ~ 150Hz
Sub ? Sonic Filter slope 12dB
Sub ? Sonic Filter Range 15Hz ~ 55Hz
Dimensions
Length 7.6′ / 195 mm
Width 5.3′ / 135 mm
Height 1.88′ / 48 mm
_____________________________________
NZ's Favourite online Outlet for Automotive parts including Clutches, Flywheels, Brakes, Water Pumps, Bearings, 4WD Accessories, parts and more.
Description
The NEO Amplifiers include a built-in variable crossovers. The crossover features a variable frequency selection for precise low pass filtering for the NEO1.5Kv2. The NEO4v2 and NEO5v2 also feature the same frequency selection with the option or high pass or low pass filtering. For added low frequency performance the amplifiers are equipped with a selectable 6dB-12dB Bass Boost @ 45Hz.
1 Channel Full Range Class D Technology
2Ω Mono load Capability
Amphibious grade conformal coating on PCB
Audiophile Grade RCA connectors
Variable 12dB High/Low-Pass Crossover Filters
Double Sided Circuit tablet
Compatible with any 4/2Ω Subwoofer
Specifications
GENERAL SPECIFICATIONS
Rated Power @ 14.4 Volts
Dynamic Power Handling
1 x 350 Watts @ 2Ω1 x 750 Watts @ 1Ω
PARAMETERS
THD (100Hz @ 1Ω) 0.04%
Bandwidth (-3 dB) 18Hz ~ 22KHz
Damping Factor (1KHz @ 4Ω) 126
S/N ratio (as weighted @ 1 Volt) 99db
Input Sensitivity 0.20V ~ 9.0V RMS
Minimum Load Impedance 1Ω
Input Pre in RCA
Mono Low Pass filter slope 12dB
Low Pass filter range 30Hz ~ 150Hz
Sub ? Sonic Filter slope 12dB
Sub ? Sonic Filter Range 15Hz ~ 55Hz
Dimensions
Length 7.6′ / 195 mm
Width 5.3′ / 135 mm
Height 1.88′ / 48 mm
