Description
The NEO Amplifiers include a built-in variable crossovers. The crossover features a variable frequency selection for precise low pass filtering for the NEO1.5Kv2. The NEO4v2 and NEO5v2 also feature the same frequency selection with the option or high pass or low pass filtering. For added low frequency performance the amplifiers are equipped with a selectable 6dB-12dB Bass Boost @ 45Hz.

5 Channel Full Range Class D Technology

2Ω Mono load Capability

Amphibious grade conformal coating on PCB

Audiophile Grade RCA connectors

Variable 12dB High/Low-Pass Crossover Filters

Bridgeable Outputs @ 4Ω Load

Double Sided Circuit tablet

Compatible with any 4/2Ω Loudspeaker

Specifications

GENERAL SPECIFICATIONS
Rated Power @ 14.4 Volts
Dynamic Power Handling
4 x 125 Watts @ 4Ω4 x 250 Watts @ 2Ω 2 x 250 Watts @ 4Ω Bridged1 x 500 Watts @ 2Ω 5th Ch

PARAMETERS
THD (100Hz @ 1Ω) 0.04%
Bandwidth (-3 dB) 18Hz ~ 22KHz
Damping Factor (1KHz @ 4Ω) 126
S/N ratio (as weighted @ 1 Volt) 99db
Input Sensitivity 0.20V ~ 9.0V RMS
Minimum Load Impedance 1Ω
Input Pre in RCA
Mono Low Pass filter slope 12dB
Low Pass filter range 30Hz ~ 150Hz
Sub ? Sonic Filter slope 12dB
Sub ? Sonic Filter Range 15Hz ~ 55Hz

Dimensions

Length 7.6′ / 195 mm
Width 5.3′ / 135 mm
Height 1.88′ / 48 mm
