VMAX10D2 – 10” DUAL 2-Ohm High-Performance Subwoofer 1600W MAX / 800W RMS

Features:
- Heavy Industrial Strength Aluminum Cast Frame
- Treated Semi-Pressed Pulped Cone
- Elevated Motor Structure for Increased Cooling
- Oversized Spider
- Black Coated 3-inch Voice Coil for Higher Thermal Capability
- Oversized Polished Black Chrome Distortion
- Polished Bumped Backplate
- Klippel Optimized Motor / Suspension Symmetry

Specifications:
SPEAKER SIZE - 10”
SPEAKER TYPE - SUBWOOFER
BI-AMPABLE YES
OHMS (PER COIL) - 2 (1 Ohm or 4 Ohm Load)
NUMBER OF VOICE COILS - DUAL
CONE MATERIAL - TREATED PAPER
BASKET MATERIAL - CAST ALUMINIUM
MAGNET TYPE - FERRITE (CERAMIC)
SURROUND MATERIAL - TREATED FOAM
VOICE COIL DIAMETER - INCH (MM) - 3"
THIELE/SMALL PARAMETERS
SENSITIVTY (1W/1M): 83.3DB
VAS (L): 24.6
XMAX (MM):0.59"(15MM)
POWER HANDLING RMS: 800W
POWER HANDLING MAX: 1600W
MOUNTING DIAMETER : 9.47” (240.5MM)

Amplifier options:
For 1 sub can use S2-A120M @ 1 Ohm Load
For 2 subs can use CVPRO2K4 @ 4 Ohm Load - You would have to use the amp bridged

SPEAKER SIZE - 12”
SPEAKER TYPE - SUBWOOFER
BI-AMPABLE YES
OHMS (PER COIL) - 4
NUMBER OF VOICE COILS - DUAL
CONE MATERIAL - TREATED PAPER
BASKET MATERIAL - CAST ALUMINIUM
MAGNET TYPE - FERRITE (CERAMIC)
SURROUND MATERIAL - TREATED FOAM
VOICE COIL DIAMETER - INCH (MM) - 3"
THIELE/SMALL PARAMETERS
SENSITIVTY (1W/1M): 86.9DB
VAS (L): 44.2
XMAX (MM):14
POWER HANDLING RMS: 1000W
POWER HANDLING MAX: 2000W
MOUNTING DIAMETER : 11.02” (280MM)
